Hydlar® ZF Reinforced Sheets & Rods
It has better slide wear
resistance (K) and rotational wear resistance (PV) from 220° to 290°F than all
other nylons and has 4x's better wear resistance than general purpose nylon.
Applications include fireplace enclosure door hinges/enclosure guides, automotive hatchback hinges, and even has replaced bronze
successfully in many food processing applications.
ASTM D-4066 PA0110R30A000000, ASTM D-5989
S-PA010R30010000000, USDA, 3A
Technical Data Sheet
|
Hydlar ZF Sheet Yellow Opaque
Thickness Tolerance +.025" |
|||||
| Thickness (in.) | Length (in.) | Width (in.) | Part # | Price | Order Online |
|---|---|---|---|---|---|
| .250 | 12 | 12 | KS-1601 | $497.93 | Add to Order |
| .375 | 12 | 12 | KS-1602 | $606.85 | Add to Order |
| .500 | 12 | 12 | KS-1603 | $661.57 | Add to Order |
| 1.00 | 12 | 12 | KS-1606 | $1,169.44 | Add to Order |
| .250 | 12 | 24 | KS-1607 | $882.74 | Add to Order |
| .375 | 12 | 24 | KS-1608 | $1,113.55 | Add to Order |
| .500 | 12 | 24 | KS-1609 | $1,213.83 | Add to Order |
| 1.00 | 12 | 24 | KS-1612 | $2,145.70 | Add to Order |
| .375 | 24 | 48 | KS-1620 | $4,305.44 | Add to Order |
| Rev. 04-23, 05-22, 02-22, 06-21 | |||||
Hydlar® Z Rods
| Hydlar® Z Rods 5 Foot Standard Lengths - Diameter Tolerance +.005" |
|||
| Diameter (in.) | Part # | Price Per Foot | Order Online |
|---|---|---|---|
| 0.250 | KR-362 | $36.48 | Add to Order |
| 0.500 | KR-363 | $50.35 | Add to Order |
| 0.625 | KR-364 | $86.63 | Add to Order |
| 0.750 | KR-365 | $64.69 | Add to Order |
| 1.00 | KR-366 | $148.07 | Add to Order |
| 1.50 | KR-709 | $269.86 | Add to Order |
| 2.00 | KR-367 | $324.29 | Add to Order |
| Rev. 03-24, 04-23, 12-22, 04-22 | |||
