Micarta Phenolic Tubing

Plastic Tubes and Tubing

Select a Wall Thickness and Grade:

.031" Wall
1/32" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.062" Wall
1/16" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.093" Wall
3/32" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.125" Wall
1/8" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.187" Wall
3/16" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.250" Wall
1/4" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.375" Wall
3/8" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.500" Wall
1/2" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

.750" Wall
3/4" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper

1.0" Wall

G10 / FR4 G11 CE Canvas G5 / G9 G7 LE Linen XX Paper


Phenolic Tube Tolerances
3 Foot Lengths: 33" ± 3"
4 Foot Lengths: 45" ± 3"
Tighter tolerances of 36" ± 1"
and 48" ± 1" can be quoted on request.
↑ Length ↑ ↓ Inside Diameter ↓
↓ Outside Diameter ↓ Turned OD
Tolerance		 Steel
Mandrel		 Built-up
Mandrel
0.125"  to  0.749" ±.005" ±.003" -
0.750"  to  1.999" ±.005" ±.004" -
2.000"  to  4.000" ±.008" ±.006" -
4.001"  -  12.000" ±.025" ** ±.010" -
12.001" - 18.000" ±.030" ** ±.030" ±.060"
18.001" - 24.000" ±.035" ** ±.040" ±.075"
24.001" - 48.000" ±.040" ** ±.060" ±.090"

   ** Tubes over 8.00" OD are wound, not turned, which
  always ship fractions of an inch larger than listed OD.

   ** Tubes turned to this OD tolerance
  can be quoted on request.
