PEEK Plastic Tubing
PEEK tubing
provides excellent chemical resistance combined with heat resistance to 480°F.
Used in steam or boiling water applications,
PEEK experiences no significant decline in its properties. Underwriters Laboratories (UL) Ratings and Food and Drug Administration (FDA) Compliant and U.S. Department of
Agriculture (USDA) Compliant and 3A Sanitary Standards (3A) Compliant.
Applications:
- High pressure liquid/gas chromatography parts
- Chemical pump gears & wear plates
- Plasma arc torch bodies
- Insulators & connectors
- Steam cleaning equipment
- Automotive manual
- Transmission thrust washers
PEEK is used in harsh applications in the Chromatography industry.
|
PEEK Coiled Tubing - Polyetheretherketone
Note Some Diameters have 3-4 week lead time to mold. |
||||||
| O.D. (in.) | I.D. (in.) | Wall (in.) | Part # | Price Per 25 Feet | Order Online | |
|---|---|---|---|---|---|---|
| .062 | .005 | .029 | KM-5294 | $112.50 | Add to Order | |
| .062 | .010 | .026 | KM-5272 | $101.00 | Add to Order | |
| .062 | .020 | .021 | KM-5284 | $101.00 | Add to Order | |
| .062 | .030 | .016 | KM-5285 | $97.00 | Add to Order | |
| .062 | .040 | .011 | KM-1141Q | $97.00 | Add to Order | |
| .077 | .062 | .008 | KM-1141W | $108.00 | Add to Order | |
| .125 | .062 | .031 | KM-5286 | $196.80 | Add to Order | |
| .125 | .080 | .027 | KM-1141Z | $192.00 | Add to Order | |
| .125 | .093 | .016 | KM-1141Y | $192.00 | Add to Order | |
| Rev. 11-22, 03-22, 06-21 | ||||||
| Coiled PEEK Tolerances | |||
| O.D. | I.D. | O.D. | I.D. |
|---|---|---|---|
| .062" | .006" | ±.003 | ±.002 |
| .062" | .010" | ±.003 | ±.002 |
| .062" | .020" | ±.003 | ±.002 |
| .062" | .030" | ±.003 | ±.002 |
| .062" | .040" | ±.003 | ±.003 |
| .077" | .062" | ±.004 | ±.003 |
| .125" | .062" | ±.005 | ±.004 |
| .125" | .080" | ±.005 | ±.005 |
| .125" | .093" | ±.005 | ±.005 |
| PEEK Straight Extruded Tubes | |||||
| O.D. (in.) | I.D. (in.) | Wall (in.) | Length (in.) | Part # | Price Per 48" |
|---|---|---|---|---|---|
| .375 | .250 | .062 | 48" | KM-25008 | $68.28 |
| .500 | .250 | .125 | 48" | KM-25009 | $128.76 |
| .750 | .250 | .250 | 48" | KM-25010 | $313.68 |
| 1.00 | .500 | .250 | 48" | KM-25011 | $470.52 |
| 1.50 | 1.00 | .250 | 48" | KM-25012 | $710.16 |
| 2.00 | 1.00 | .500 | 48" | KM-25013 | $1,488.80 |
| Rev. 11-22, 03-22 | |||||
