PFA Chemflour® Tubing
Excellent chemical resistance. Retains higher mechanical strength at elevated temperatures compared to PTFE.
High resistance to stress cracking. Made from standard PFA resin (perfluoroalkoxy)
| PFA Chemflour® Tubing | |||||||
| Part # | OD (in.) | ID (in.) | Wall (in.) | Coil Length | Working PSI @ 70F | Price Per Coil | Order Online |
|---|---|---|---|---|---|---|---|
| KM-4874 | .125 | .063 | .031 | 50' | 350 | $264.38 | Add to Order |
| KM-4873 | .188 | .125 | .031 | 50' | 230 | $290.25 | Add to Order |
| KM-5303 | .250 | .125 | .062 | 50' | 383 | $1,737.00 | Add to Order |
| KM-4872 | .250 | .156 | .047 | 50' | 270 | $806.63 | Add to Order |
| KM-5301 | .250 | .187 | .031 | 50' | - | $1,174.50 | Add to Order |
| KM-4871 | .313 | .188 | .063 | 50' | 290 | $1,328.63 | Add to Order |
| KM-5300 | .313 | .250 | .031 | 50' | - | $1,850.75 | Add to Order |
| KM-4870 | .375 | .250 | .063 | 50' | 240 | $1,472.63 | Add to Order |
| KM-4869 | .438 | .375 | .031 | 50' | 180 | $1,101.38 | Add to Order |
| KM-4868 | .500 | .375 | .063 | 50' | 180 | $1,836.00 | Add to Order |
| KM-23617 | .500 | .437 | .031 | 50' | 133 | $2,452.50 | Add to Order |
| KM-4867 | .562 | .500 | .031 | 50' | 160 | $1,391.63 | Add to Order |
| Rev. 10-23, 04-23, 09-22, 03-22 | |||||||
|
PFA Industrial Grade Tubing
Natural |
|||||
| Part # | OD (in.) | ID (in.) | Wall (in.) | Price | Order Online |
|---|---|---|---|---|---|
| KM-23830 | .062 | .031 | .016 | $121.50 Per 25 Ft. | Add to Order |
| KM-4567 | .125 | .062 | .031 | $22.50 Per 25 Ft. | Add to Order |
| KM-4568 | .156 | .093 | .031 | $38.25 Per 25 Ft. | Add to Order |
| KM-4569 | .188 | .125 | .031 | $35.44 Per 25 Ft. | Add to Order |
| KM-4584 | .188 | .062 | .062 | $78.19 Per 25 Ft. | Add to Order |
| KM-4585 | .250 | .125 | .062 | $86.63 Per 25 Ft. | Add to Order |
| KM-23815 | .250 | .156 | .047 | $517.28 Per 50 Ft. | Add to Order |
| KM-5277 | .250 | .187 | .031 | $144.00 Per 25 Ft. | Add to Order |
| KM-4570 | .313 | .188 | .062 | $102.94 Per 25 Ft. | Add to Order |
| KM-4571 | .375 | .250 | .062 | $144.56 Per 25 Ft. | Add to Order |
| KM-4572 | .437 | .313 | .062 | $752.63 Per 25 Ft. | Add to Order |
| KM-4573 | .500 | .375 | .062 | $203.06 Per 25 Ft. | Add to Order |
| KM-4575 | .625 | .500 | .062 | $346.50 Per 25 Ft. | Add to Order |
| KM-4577 | .750 | .625 | .062 | $424.69 Per 25 Ft. | Add to Order |
| KM-23936 | .750 | .687 | .031 | $1,005.75 Per 25 Ft. | Add to Order |
| KM-4596 | .875 | .750 | .062 | $1,215.00 Per 25 Ft. | Add to Order |
| KM-4597 | 1.00 | .875 | .062 | $579.94 Per 25 Ft. | Add to Order |
| KM-4598 | 1.125 | 1.000 | .062 | $658.13 Per 50 Ft. | Add to Order |
| Rev. 10-23, 04-23, 03-22, 09-21 | |||||
